| Mechanical & Environmental Characteristics | |
| Dimension | 23.8cmx 14.1cm x 6.7cm |
| Material | SR Polypropylene |
| Color | Yellow |
| Weight | 0.75kg |
| Packaging | Rugged, hard-shell transit case |
| Storage Temperature | -40℃ to +85℃ |
| Operating Temperature | -40℃ to +85℃ |
| Humidity | 0 to 95%, non-condensing |
| Fiber & Connector Characteristics | |
| Fiber Types | G652D, G657A, OM1, OM2, OM3, OM4 |
| Fiber Length (m) | 500/1000/2000m |
| Typical Loss | <0.5dB @ 1310 for 1000 meters |
| Connector Type | SC/LC/FC/ST |
| Polish | UPC/APC |
| Return Loss* | UPC>=50dB, APC>=60dB, PC>=35dB |
| Repeatability (dB) | <=0.2 (1000 times) |
| Exchangeability (dB) | <=0.2 |
Feature & Application
- Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration
- Compound Latch for positive seal and easy opening with locking feature.
- Nonmetal construction will not dent, corrode, or conduce electricity
- Water and dust proof allowing the unit to be taken into almost any environmen
- Auto Purge Valve for changes in altitude and temperature
